ISO/IEC 29341-24-10:2017 PDF

Information technology — UPnP Device Architecture — Part 24-10: Internet gateway device control protocol — Level 2 — Wide area network internet protocol — Connection service

Первая страница стандарта ISO/IEC 29341-24-10:2017

Открыть превью (PDF)

Название (английский):

ISO/IEC 29341-24-10:2017

Information technology — UPnP Device Architecture — Part 24-10: Internet gateway device control protocol — Level 2 — Wide area network internet protocol — Connection service

Статус документа:: Действующий
Формат:: Электронный (PDF)
Количество страниц:: 65
Дата публикации:: 13 сентября 2017 г.
Издание:: ISO/IEC IS 29341 edition 1 version 1
ICS:: 35.200

Язык документа:

ruen

Срок поставки:11 раб. дн. (перевод)

Цена:975 €

Описание (английский):

ISO/IEC 29341-24-10:2017 specifies the characteristics of the UPnP networked service named WANIPConnection, version 2. This service definition is compliant with UPnP Device Architecture 1.0 [1] . It is one component of the Device Control Protocol for the UPnP Internet Gateway Device (see [3]). This service enables a UPnP control point to: - configure and control an IP connection between a LAN client on one side of an Internet gateway (see [3]) and a WAN host on the other side; - manage any physical WAN interface?such as DSL or cable?that supports an IP connection. This service is a required in a WANConnectionDevice (see [5]) when the device supports an IP connection.

Технические детали

Технический комитет: ISO/IEC JTC 1 - Information technology
SKU: ISO/IEC 29341-24-10:2017

Abstract

Overview

ISO/IEC 29341-24-10:2017 defines the WANIPConnection v2 service for UPnP Internet Gateway Devices (IGD). Aligned with the UPnP Device Architecture 1.0, this standard specifies the network service used by a UPnP control point to configure and control IP connections and manage WAN interfaces (DSL, cable, etc.). It is a required service for a WANConnectionDevice that supports IP connections and is a component of the UPnP IGD Device Control Protocol.

Key topics and technical requirements

Service model and XML description: Formal service type, state variables and action signatures in an XML service description compliant with UPnP Device Architecture.
State variables: Definitions for connection-related variables such as ConnectionType, ConnectionStatus, ExternalIPAddress, PortMappingNumberOfEntries, NATEnabled, RSIPAvailable, Uptime, and error/state enumerations.
Actions (control API): Standard actions include SetConnectionType(), GetConnectionTypeInfo(), RequestConnection(), RequestTermination(), ForceTermination(), GetExternalIPAddress(), AddPortMapping(), AddAnyPortMapping(), DeletePortMapping(), DeletePortMappingRange(), GetListOfPortMappings(), and others for managing auto/idle disconnect and port mappings.
Port mapping and NAT control: Procedures and error codes for adding, listing, and deleting port mappings (port forwarding), lease durations, protocols, and port ranges.
Eventing and moderation: Rules for state change event notifications (e.g., ExternalIPAddress, ConnectionStatus, PortMappingNumberOfEntries) so control points can react to gateway changes.
Backward compatibility and Level 2 features: Clarifies changes from earlier WANIPConnection version(s) and compatibility behaviors.

Applications and who uses it

Home and SOHO router vendors / CPE manufacturers: Implement this service in device firmware to expose WAN configuration and NAT/port-forwarding control to UPnP control points.
Router firmware and SDK developers: Use the standard to implement compliant APIs and XML service descriptions.
Application developers and UPnP control point authors: Enable automatic NAT traversal, remote access, and port mapping for games, VoIP, remote management, NAS, and IoT devices.
Network integrators and system testers: Validate IGD behavior, eventing, and error handling against the standard to ensure interoperability.

Related standards

ISO/IEC 29341 family - UPnP Device Architecture and related Device Control Protocol parts (Internet Gateway Device specifications).
UPnP Device Architecture 1.0 (baseline architecture and requirements for UPnP services).

By following ISO/IEC 29341-24-10:2017, device makers and software developers ensure interoperable UPnP WAN IP connection control, consistent NAT/port-mapping behavior, and robust remote-access capabilities across Internet gateway devices.

Overview

Key topics and technical requirements

Service model and XML description: Formal service type, state variables and action signatures in an XML service description compliant with UPnP Device Architecture.
State variables: Definitions for connection-related variables such as ConnectionType, ConnectionStatus, ExternalIPAddress, PortMappingNumberOfEntries, NATEnabled, RSIPAvailable, Uptime, and error/state enumerations.
Actions (control API): Standard actions include SetConnectionType(), GetConnectionTypeInfo(), RequestConnection(), RequestTermination(), ForceTermination(), GetExternalIPAddress(), AddPortMapping(), AddAnyPortMapping(), DeletePortMapping(), DeletePortMappingRange(), GetListOfPortMappings(), and others for managing auto/idle disconnect and port mappings.
Port mapping and NAT control: Procedures and error codes for adding, listing, and deleting port mappings (port forwarding), lease durations, protocols, and port ranges.
Eventing and moderation: Rules for state change event notifications (e.g., ExternalIPAddress, ConnectionStatus, PortMappingNumberOfEntries) so control points can react to gateway changes.
Backward compatibility and Level 2 features: Clarifies changes from earlier WANIPConnection version(s) and compatibility behaviors.

Applications and who uses it

Home and SOHO router vendors / CPE manufacturers: Implement this service in device firmware to expose WAN configuration and NAT/port-forwarding control to UPnP control points.
Router firmware and SDK developers: Use the standard to implement compliant APIs and XML service descriptions.
Application developers and UPnP control point authors: Enable automatic NAT traversal, remote access, and port mapping for games, VoIP, remote management, NAS, and IoT devices.
Network integrators and system testers: Validate IGD behavior, eventing, and error handling against the standard to ensure interoperability.

Related standards

ISO/IEC 29341 family - UPnP Device Architecture and related Device Control Protocol parts (Internet Gateway Device specifications).
UPnP Device Architecture 1.0 (baseline architecture and requirements for UPnP services).
